The Hastelloy X Bolts contain nickel, chromium, along with iron and molybdenum in its chemical composition. This alloy provides great resistance towards oxidation. Their oxidation resistance is up to 2200 degrees Fahrenheit. These Hastelloy X Bolts also possess the characteristics of fabricability. These Hastelloy X Bolts also have great strength at highly elevated temperatures.
The UNS N06002 Hastelloy X Bolts are resistant to stress corrosion cracking. These also have the property of being weldable. And these can also be formed easily. Along with its properties of resisting corrosion, possessing fabrication properties, it is also very applicable in applications that might be subjected to or are at highly elevated temperatures. These Hastelloy X Bolts also provide good strength at elevated temperatures while resisting oxidation.
These Hastelloy X Fasteners are manufactured from the great quality of raw materials to manufacture an excellent quality of the product. Also, these Hastelloy X Bolts could be available in different shapes, sizes, and dimensions depending upon the requirements and specifications provided by the client or the need of the applications. These Hastelloy X Bolts undergo a series of destructive and non-destructive tests to test and improve the quality of the products.
Along with all this, accuracy, as well as the efficiency, is ensured while producing these fasteners. As these Hastelloy X Bolts have many characteristics as well as properties, they are used in a large number of industrial applications such as chemical industries, paper processing industries and so on.
| Specifications | ASTM F593, F594, F1554 / ASME SF593, F594, F1554 |
| Standard |
DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M as per defined in ASME B16.5 standard length ANSI B 18.2.4 2M as per defined in ASME B18.2.2 |
| Size | M3 - M56 | 3/6" to 2" | Custom Sizes |
| Length | 3 mm to 200 mm | Custom Sizes |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Threads available | UNF, BSW, BSF, METRIC, UNC, or as required |
| Threads Configuration |
ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Test Certificate | As per EN 10204 / 3.1 Manufacturer Test Certificate, PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Raw materials Source | JSPL, Mukund Steel, Tata Steel, Dhamm Steel, Usha Martin,etc. |
| Packing | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating |
Cadmium Coating Hot Dipped Galvanizing Coating Ptfe Coated Phosphate Coating Teflon Coating Xylon Coating Zinc Coating |
| STANDARD | UNS | WERKSTOFF NR. |
| Hastelloy X | N06002 | 2.4665 |
| Element | Ni | C | Mo | Mn | Si | Fe | Cu | Ti | Co | Cr |
| Hastelloy X | Balance | 0.05-0.15 | 8.0-10.0 | 1.0 max | 1.0 max | 17.0-20.0 | 0.50 max | 0.15 max | 0.5-2.5 | 20.5-23.0 |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 9.2 g/cm3 | 1370 °C (2500 °F) | Psi – 51,000, MPa – 350 | Psi -1,10,000, MPa -760 | 40 % |
