Regular Pattern Eyebolts

Regular Pattern Eyebolts


Regular Pattern Eyebolts

How It Work?

Laboratory Tested
Quality Assurance
On Time Delivery
Shipping Globally
Best Services

Nominal Size A B C D E F G H Wx Wy Wz
Shank Dia Shank Length Eye ID Nominal Eye OD Eye Sect Dia Overall Length Min Length Full Thread Thread Size UNC-2A Safe Working Load, lb at 0 Deg1 Safe Working Load, lb at 45 Deg1 Safe Working Load, lb at 90 Deg1
1/4* 0.25 0.25
0.28		 1.00
1.06		 0.69
0.81		 1.19 0.19
0.25		 2.06
2.38		 0.75 1/4-20 or .250-20 400 80 60
5/16* 0.31 0.31
0.34		 1.12
1.19		 0.81
0.94		 1.44 0.25
0.31		 2.44
2.75		 0.81 5/16-18 or .3125-18 800 160 120
3/8* 0.38 0.38
0.41		 1.25
1.38		 0.94
1.06		 1.69 0.31
0.38		 2.81
3.19		 0.88 3/8-16 or .375-16 1400 280 210
7/16 0.44 0.44
0.47		 1.38
1.50		 1.00
1.12		 1.81 0.34
0.41		 3.06
3.44		 1.00 7/16-14 or .4375-14 2000 400 300
1/2* 0.50 0.50
0.53		 1.50
1.62		 1.12
1.25		 2.12 0.44
0.50		 3.50
3.88		 1.12 1/2-13 or .500-13 2600 520 390
9/16 0.56 0.56
0.59		 1.62
1.75		 1.19
1.31		 2.25 0.47
0.53		 3.75
4.12		 1.25 9/16-12 or .5625-12 3000 600 450
5/8* 0.62 0.62
0.66		 1.75
1.88		 1.31
1.44		 2.56 0.56
0.62		 4.19
4.56		 1.38 5/8-11 or .625-11 4000 800 600
3/4* 0.75 0.75
0.78		 2.00
2.12		 1.44
1.56		 2.81 0.62
0.69		 4.69
5.06		 1.62 3/4-10 or .750-10 6000 1200 900
7/8* 0.88 0.88
0.91		 2.25
2.38		 1.56
1.69		 3.19 0.75
0.81		 5.31
5.69		 1.81 7/8-9 or .875-9 6600 1300 1000
1* 1.00 1.00
1.06		 2.50
2.62		 1.69
1.81		 3.56 0.88
0.94		 5.94
6.31		 2.06 1-8 or 1.000-8 8000 1600 1200
1-1/8 1.12 1.12
1.19		 2.75
2.88		 1.94
2.06		 4.06 1.00
1.06		 6.69
7.06		 2.31 1-1/8-7 or 1.125-7 10000 2000 1500
1-1/4* 1.25 1.25
1.34		 3.00
3.12		 2.12
2.25		 4.44 1.09
1.16		 7.31
7.69		 2.50 1-1/4-7 or 1.250-7 15000 3000 2250
1-1/2* 1.50 1.50
1.59		 3.50
3.62		 2.44
2.56		 5.19 1.31
1.38		 8.56
8.94		 3.00 1-1/2-6 or 1.500-6 18000 3600 2700
1-3/4 1.75 1.75
1.84		 3.75
3.88		 2.75
3.00		 6.00 1.50
1.62		 9.50
10.12		 3.19 1-3/4-5 or 1.750-5 22000 4400 3300
2* 2.00 2.00
2.09		 4.00
4.25		 3.06
3.44		 6.88 1.75
1.88		 10.56
11.44		 3.38 2-4-1/2- or 2.000-4.50 26000 5200 3900
2-1/2* 2.50 2.50
2.62		 5.00
5.25		 3.81
4.19		 8.50 2.19
2.31		 13.19
14.06		 4.25 2-1/2-4 or 2.500-4 32000 6400 4800

NOTES:*Preferred
These safe working loads are based on the following percentages of minimum proof loads shown in ASTM A 489; 0 Deg - 66.6 per cent, 45 Deg - 13.3 per cent, 90 Deg - 10.0 per cent.
